Line Connection Booksize
2.5 Basic Line Filter for Active Line Modules with Active Interface Module
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
51
2.5.3.2 Line/power connection
Table 2-5 Connection type
Terminals Designations
Line supply connection (line supply) L1, L2, L3, PE
Load connection (load) L1´, L2´, L3´, PE
Basic Line Filter for Active Line Module with Active Interface Module
55 kW Screw terminal: 95 mm
2
PE connection: M6/6 Nm
1)
80 kW
120 kW
Screw terminal: 95 mm
2
PE connection: M10/10 Nm
1)
1)
for ring cable lugs to DIN 46234
