8.2 DC link rectifier adapter for Booksize format
Booksize power units
462 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
8.2.3.2 DC link connection
Table 8-7 DC link rectifier adapter – description of the terminals
Terminal Function Technical specifications
DCP DC link positive
DCN DC link negative
Supply voltage:
720 V-VDE/600 V-UL
Direct supply 4 – 10 mm²
Current carrying capacity: 36 A
connection cross-section: 4 – 10 mm²
Stripped length: 11 mm
Direct supply 35 – 95 mm²
Current carrying capacity: 200 A
connection cross-section: 35 – 95 mm²
Stripped length: 27 mm
