Cabinet Design and EMC Booksize
9.7 Cooling
Booksize power units
536 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
Component Order number Clearance [mm]
Line reactor for smart line module
5 kW – 36 kW
6SL3000-0CExx-0AAx
100
Active line module
16 kW – 55 kW
80 kW – 120 kW
6SL3130-7TExx-xAAx
6SL3130-7TExx-xAAx
80
80 (additional 50 in front of fan)
Smart Line Module Booksize format
5 kW – 36 kW
6SL3130-6AExx-0AAx
80
Smart Line Module Booksize Compact
format
16 kW
6SL3430-6TE21-6AAx
80
Basic Line Module
20 kW – 100 kW
6SL3130-1TExx-xAAx 80
Motor Module Booksize format < 132 A 6SL312x-1TExx-xAAx 80
Motor Module Booksize format
132 A a. 200 A
6SL312x-1TE3x-xAAx
80 (additional 50 in front of fan)
Motor Module Booksize Compact
format
1.7 A - 18 A
6SL3420-xTExx-xAAx
80
Braking Module 6SL3100-1AE31-0AAx 80
Control Supply Module 6SL3100-1DE22-0AAx 80
Capacitor module 6SL3100-1CE14-0AAx 80
The specifications regarding ventilation clearances for two-tier configurations are provided in
sect. "Drive Line-Up".
