Cabinet Design and EMC Booksize
9.5 Information about electromagnetic compatibility (EMC) and cable routing
Booksize power units
Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
521
Type Maximum length [m]
Power cable between line filter and line reactor 10 (shielded/unshielded)
1)
Power cable between line reactor and Line
Module
10 (shielded/unshielded)
1)
Power cable between
Motor and Motor Module to In = 9 A
50 (shielded)
75 (unshielded)
Power cable between
Motor and Motor Module In = 18 A
70 (shielded)
100 (unshielded)
Power cable between
Motor and Motor Module In ≥ 30 A
100 (shielded)
150 (unshielded)
DRIVE-CLiQ signal cables MC500 100
DRIVE-CLiQ signal cables MC800 50
DRIVE-CLiQ signal cables FIX 70
Cable between the Braking Module and braking
resistor
10
1)
To comply with EMC limit values, shielded cables (preferably Motion-Connect cables) must be used.
2)
For greater lengths, suitable wiring must be connected by the user to provide overvoltage protection.
