Siemens SIROTEC Equipment Manual

Cabinet Design and EMC Booksize
9.7 Cooling
Booksize power units
544 Manual, (GH2), 06/2008, 6SL3097-2AC00-0BP6
Unit Power loss
Wideband Line Filter for Active Line Modules
16 kW W 70
36 kW W 90
55 kW W 110
80 kW W 150
120 kW W 200
Basic Line Filter for Smart Line Modules
5 kW W 5
10 kW W 9
16 kW W 16
36 kW W 28
Basic Line Filter for Basic Line Modules
20 kW W 144
40 kW W 283.6
100 kW W 628
Line reactors for Active Line Modules
16 kW W 170
36 kW W 250
55 kW W 350
80 kW W 450
120 kW W 590
Line reactors for Smart Line Modules
5 kW W 62
10 kW W 116
16 kW W 110
36 kW W 170
Line reactors for Basic Line Modules
20 kW W 130
40 kW W 270
100 kW W 480
Sensor Modules
SMC10 W < 10
SMC20 W < 10
SMC30 W < 10
Additional system components
TM15 W < 3
TM31 W < 10
TM41 W 10
TM54F W 4.5
DC link components
Braking Module W 20
Capacitor Module W 25
