Simplex 4100 Operator's Manual

1-1
This chapter describes the operator interface panel for the following versions of the 4100 Fire
Indicator Panel (FIP).
• A 4100 Fire Indicator Panel operating in standalone mode.
• A 4120 Network Indicator Panel (which is a 4100 connected to a network).
• A 4120-8821 Network Display Unit with Command Centre.
Note: The operations described in this manual may vary due to custom
programming and local code requirements.
Refer to the page number listed in this table for information on a specific topic.
Topic See Page #
Door Up – Firefighter Facility Operator Interface 1-2
Door Down – Service Related Features 1-5
Chapter 1
Overview
Introduction
In this Chapter
firealarmresources.com

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
