Simplex 4100 Operator's Manual

A-9
Zone Status: 2 line by 80 character backlight Liquid Crystal
Display
LED Status Indicators: Alarm, Fault and Isolate, EXT Bell (Isolate), WARN
SYS (Isolate), AC Power
Audible Buzzer: Alarm And Fault Indications, Keypress feedback
Operator Keypad:
AS4428 Firefighter Facility: Ext Bell Isolate, Warn Sys Isolate, Prev, Next, Ack,
Reset Power
Service Technician: 20 keys including:- Alarm Test, Fault Test, Keypad,
Fault Isolate, Battery Test and Lamp test
• WALK TEST System Test
• 4 Operator Access Levels
• 600 Event Historical Logging
• Zone selectable Alarm Verification
• Individual Circuit Disconnect / Isolate
• Nonvolatile Flash EPROM for field editable program changes
4100 Specifications, Continued
INDICATORS and
DISPLAY
KEYPAD
CONTROLS
SOFTWARE
FEATURES
firealarmresources.com

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
