1-6
The "DISPLAY " keypad provides keys that allow users with appropriate access level the
ability to perform controlling functions on the system zones, MAPNET devices, signals, and
auxiliary control relays. Four keys are associated with the Display keypad.
Key Description
<FUNCTION> Key
The <FUNCTION> key is used to obtain more information
concerning the point in the display. Pressing the <FUNCTION>
key scrolls through all the status information. This data will be
displayed on the bottom line.
A point will normally be displayed with its forty character custom
label on the top line. If no custom label exists for the point, the top
line will display the point identifier.
The bottom line will contain the device type and its present status.
Point types are assigned when the system is configured, and are
determined by their card type and the physical devices on its
zones. The following are available for display on the alphanumeric
display.
• Point address and Zone number.
• Card type and Point type.
• Present Status (Normal, Alarm, Fault).
• Disconnect/Disable Status.
• McCulloh Fault (Status of Class "A" Cards).
• Relay status for Control or Signal Points.
• Verification Tallies for Verification Zones.
• Coding Status for Coded Zones.
• Control Priority for Relays.
• Feedback Point Status for Outputs.
• Counts for Lists and Virtual Zones.
In addition to the items above, the following items are for
TrueAlarm sensors only:
• Present sensitivity selected
• Average value
• Alarm value
• Current value (per cent of alarm)
• Peak value (per cent of Alarm)
Continued on next page
Door Down – Service Related Features, Continued
Display Keypad
