If the passcode entered in Step 5 is correct, the following message is shown.
After a brief pause, the system displays the granted access level, such as the level 2 message
shown below.
Press the <CLR> key twice. The display shows the system status, as shown below.
Failure to log out allows unauthorized personnel access to the various passcode protected
functions. If no keypad activity is detected for ten minutes, the system returns to Level 1
access.
Perform the following procedure to log out and return the operator access level to Level 1.
1. Press the <MENU> key. The following message is displayed.
2. Press the <ENTER> key. The following message is displayed.
Note: Logging in at access level 4 creates a non-clearable fault that requires the
system to be restarted to clear. This ensures that the system is returned to its normal
operating mode following service.
Continued on next page
Logging In and Out of the System, Continued
Log In Procedure,
(continued)
Log Out Procedure
Enter a Passcode followed by <ENTER>
ACCESS GRANTED
F1 = Login F2 = Logout
CURRENT ACCESS LEVEL = 2
F1 = Login F2 = Logout
CURRENT ACCESS LEVEL = 2
Press <NEXT> or <PREVIOUS> to scroll
Change Access Level?
F1 = Login F2 = Logout
CURRENT ACCESS LEVEL = 2
