5-2
Every system point is part of the “Select a List of Points” list in the main menu. All points
can be displayed sequentially by address order using this list option. To facilitate the search
for a particular point, lists may be selected by type groupings (monitors, signals, auxiliary,
input/output, pseudo points, etc.). A list of points may be selected, then scrolled through by
using the <NEXT> and <PREVIOUS> keys.
The following lists are available for selection with the “Select a List of Points” option from
the Main Function Menu:
• All Monitor Zones
• All Signal Points
• All Auxiliary Relay Points
• All Auxiliary Feedback Points
• All Zones of 24-Point I/O Card
• All Digital Pseudo Points
• All Analogue Pseudo Points
• All List Pseudo Points
• All Points by Address List
• All Network Points.
1. Press the MENU key to enter the panel’s menu system.
2. Press the NEXT key until the alphanumeric display reads as follows:
3. Press ENTER. The display reads as follows:
4. Press the NEXT key to scroll through the categories of points until the appropriate
category is shown. Press the ENTER key. The first point in the selected category
appears. In the example below, the point shown is the first one in the monitor zone
category.
5. Press the NEXT key to scroll through the list of points in the category. When the point
that you want to select is displayed.
Selecting Points from the Menu
Overview
Procedure
Press
<NEXT>
or
<PREVIOUS>
to
scroll
Select a List of Points?
Press ENTER to select a list of points
All Monitor Zones?
MONITOR CARD 1 ZONE NUMBER 1
FIRE MONITOR ZONE NORMAL
To Next Page
