A-7
System Capacity 1,000 points of addressable input / output devices or
conventional zones.
Cabinet Size(mm) Dependent on system configuration
Cabinet Material 1.5mm Mild grade steel
Cabinet Finish Powder coated
Cabinet Colour Magnolia Ripple
Mounting Wall mount
Mains Input 240V AC, +6%,-10%, 50Hz
Internal Power Supply 24V DC @ 8.0A
Standby Battery 24V sealed lead acid up 110Ah
Battery Charger 27.6V DC (nominal) @ 4.0A,
PSU Supervision Charger high/low, Battery low/fail
Temperature -5 C to 45 C
Humidity 10% to 90% RH non-condensing.
PSU Heat Loss 85 watts (under full load)
Note: The 4100A-0157 PSU does not provide the option to disconnect the battery
when the final voltage is reached as this is not a requirement of AS4428.1
Maximum Number: 119 modules
4100-5004 Conventional zone module
Eight zone circuits per module
Supports standard 20V detectors plus normally open
contact devices
4100-3003 Eight CPU controlled auxiliary relays per module
SPDT contacts rated for 3 amps @ 24VDC or
30VAC
4100-0113 RS-232 / 2120 Communications Module
Provides two RS-232-C outputs for remote printers
and/or CRT
Five RS-232-C ports maximum per 4100 system.
Can be configured for communication with a host
2120 system, or it can be configured as a Computer
Port for communications to a remote system (i.e.
BMS or BAS Systems).
4100-0149 4120 Modular Network Interface Module
Provides Network Interface with plug-in media
modules for:
RS485 Communications copper cable
Fiber Optics Media Card
4100-0142 RS485 Communications copper cable Media
module
4100-0143 Fiber Optics Media Card
Continued on next page
4100 Specifications
General
Expansion Modules
