10-8
Once the passcode has been entered, you may enter the Walk Test™ mode by performing the
following procedures.
1. Press the MENU key. The LCD shows the following message.
Press <N
EXT> o
r <PREVIO
US> to
Scroll
Change Access Level?
2. Press the NEXT key until the LCD displays the following message.
Press <N
EXT> o
r <PREVIO
US> to
Scroll
Enable Walk Test?
3. Press the ENTER key. The following message is displayed.
F1 = on>OFF F2 = no>LOG F3 = ?>ZONE F4 = NO<sig
WALK TEST GROUP 0
4. Select the desired Walk Test™ data using Function keys <F1> through <F4>.
• <F1> Key - Function key <F1> is used to toggle the Walk Test™ mode.
Turn Walk Test™ ON and OFF by pressing the <F1> key.
Pressing this key causes an arrow to point to the active state (which
is displayed in capital letters).
• <F2> Key - Function key <F2> is used to enable/disable logging of Walk
Test™ events. Walk Test™ events are logged into the Historical
Fault log if selected. Pressing this key causes an arrow to point to
the active state (which is displayed in capital letters). By default,
logging is enabled.
• <F3> Key - Function key <F3> is used to enable/disable zone coding.
Pressing this key causes an arrow to point to the active state. By
default, zone coding is enabled.
• <F4> Key - Function key <F4> is used to enable/disable the silent Walk
Test™. Pressing this key causes an arrow to point to the active
state (which is displayed in capital letters). By default, the silent
Walk Test™ is enabled.
Continued on next page
Walk Test™ PROCEDURESWalk Test™ PROCEDURES, Continued
How to Enter Walk
Test Mode
