Simplex 4100 Operator's Manual

9-4
Every card, including the master controller and all option cards, has a series of Card Status
Points associated with it.
1. Press the MENU key.
2. Press the NEXT and PREV keys until the prompt reads, “Display Card Status?”
3. Press ENTER. The card status for the first card in the system appears.
4. Press the NEXT and PREV keys. Each time you press the key, the status for the next
card in the system appears.
To view power supply voltage and current readings, perform the following procedure.
1. Press the <MENU> key on the DISPLAY/ACTION keypad. Then press the <NEXT>
key six times.
The alphanumeric display reads:
Press <NEXT> or <PREVIOUS> to scroll
Display Card Status?
2. Press the <ENTER> key on the ENTRY keypad. Then press the <NEXT> key once (or
until the display reads:)
CARD n, POWER SUPPLY/CHARGER
CARD STATUS NORMAL
NOTE: “n” = Card number
3. Press the <ENTER> key. Then, using the <NEXT> or <PREVIOUS> key to scroll,
check voltage/current readings on the Power Supply/Charger card.
Viewing Card Status Information
Procedure
Power
Supply/Charger
Voltage and Current
Readings
firealarmresources.com

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
