Simplex 4100 Operator's Manual

4-5
It may be necessary during maintenance of the system to turn the outputs (notification
appliances and relays, for example) off. This prevents maintenance actions that generate an
alarm condition from triggering the NACs or relays.
1. Select the output point that you want to turn off. Refer to Chapter 5 for information on
selecting points.
2. Press the OFF/FLT TEST key.
3. Press the ENTER key to confirm the operation.
1. Select the output point that you want to force ON. Refer to Chapter 5 for information on
selecting points.
2. Press the ON/ALM TEST key.
3. Press the ENTER key to confirm the operation.
Turning an output point on or off generates a “Manual Override Trouble,” which is used to
remind you that the point has been manually turned on or off. When you are ready to return
the system to automatic operation (i.e., system not operator controls the outputs), you need to
acknowledge the trouble (individual acknowledge systems only), select the point, and then
press the <AUTO> key.
Turning a Point ON or OFF
Overview
Turning a Point OFF
Turning a Point ON
Returning a Point to
Automatic Operation
firealarmresources.com

Simplex 4100 Specifications

General

Type	Fire Alarm Control Panel
Manufacturer	Simplex
Model	4100
Network Capability	Yes
Addressable	Yes
Power Supply	120/240 VAC, 50/60 Hz
Display	LCD
Annunciator Support	Yes
Battery Backup	Yes
Releasing Capability	Yes
Max Devices	Depends on configuration
Max Notification Appliance Circuits (NAC)	Varies with configuration
Max Releasing Circuits	Varies with configuration
Max Remote Annunciators	Varies with configuration
Communication Ports	Multiple
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	Up to 93% RH, non-condensing
NAC Outputs	4 (expandable)
Networking	Yes
