1-7
Key Description
<MENU> Key
The <MENU> key will call up the Main Menu and display the first
option on the list. The Main Menu provides operations which are
separate from those used for fire alarm conditions. These
non-critical functions are selected with the <MENU> key.
The <NEXT> and <PREVIOUS> keys, located within the
Firefighter Facility are used to scroll through the menu options.
The <ENTER> key selects the displayed option. The following are
the Main Menu options:
A. Access Level
B. Set Time and Date?
C. Display Historical Alarm/Fault Log?
D. Select a List of Points?
E. Display Software Revision Level?
F. Display Card Status?
G. Enable Walk Test?
H. Run Diagnostic Functions?
I. Programmer Download?
J. Exit Menu List?
<LAMP TEST>
Key
Pressing the <LAMP TEST> key will turn on the five Control Key
indicators, Isolate indicator, System Alarm indicator, System Fault
indicator, and the LEDs on local indicator/switch modules. All
segments on the alphanumeric display will be turned on as a test
pattern. After a three seconds sustained press, the Tone-alert will
be turned on. When the <LAMP TEST> key has been released,
all LEDs, alphanumeric display, and tone-alert will be restored to
their previous states.
<DISPLAY TIME>
Key
Pressing this key does either of the following:
• When a point is selected, it displays the time at which a
specific alarm, fault, or isolate event occurred. To do this, you
first press the ALARM ACK, FAULT ACK, or ISOLATE ACK
key to display the list of events. Use the NEXT or PREV keys
to scroll through the list of events. When the event you want is
displayed, press the DISPLAY TIME key. The system then
searches the appropriate history log and displays the last
alarm, trouble, or isolate condition associated with the selected
point.
• Displays the system time when a point is not selected.
Continued on next page
Door Down – Service Related Features, Continued
Display Keypad,
(continued)
