Simplex 4100 Operator's Manual

10-13
3. Press the <ENTER> key. The alphanumeric display shows the following message.
Please stand by . . .
ZONE 12 will ENABLE in 60 seconds
WARNING
If the zone is still in alarm, a WARNING is displayed which tells you
that the system will sound an alarm if the timer (60 seconds) times out.
TO ABORT THE ENABLE, PRESS THE <DISABLE> KEY. If an
alarm condition exists, the following is shown on the alphanumeric
display.
** WARNING ** Press <DISABLE> to abort
ZN12 will ALARM in 60 seconds
IF THE ABOVE WARNING IS SHOWN ON the ALPHANUMERIC
DISPLAY, PRESS the <DISABLE> OR AN <ACK> KEY. FAILURE
TO ABORT THE ENABLE WILL CAUSE AN ALARM
CONDITION.
If the enable process is successful, the following message is shown on the alphanumeric
display.
ENABLE COMPLETED
4. Repeat steps 1 through 3 above to enable required points.
5. Press the <CLR> key to exit. This will allow the panel to show the Time and Date.
CALL YOUR LOCAL SIMPLEX BRANCH OFFICE, WHICH IS LISTED IN THE
YELLOW PAGES, FOR ALL MALFUNCTIONS, OR IF YOU WOULD LIKE A
QUALIFIED SIMPLEX TECHNICIAN TO ASSIST YOU WITH INSTALLATION,
TESTING AND TROUBLESHOOTING THE SYSTEM.
Walk Test™ PROCEDURES, Continued
How to Enable a
Disabled Point,
(continued)
What to do in Case
of System
Malfunction
