Argus Radar - TROUBLESHOOTING
988-10187-004 5.4
5.4.3 ANTARES Assy Replacement
Required Tools
Socket wrench 7 mm
Torx wrench T20
Removing (Figure 5.3)
1. By following the procedure of Para 5.4.1, remove the DISPLAY CORE
UNIT cover.
Remove the SMB connectors, the flat cable and all terminal boards connectors
connected to the board. By taking note of their position.
By means of the 7 mm socket wrench and the T20 Torx wrench, loosen the
nuts (pos. 2) and screws (pos. 1) fixing the board (pos. 3).
Remove the assy.
Installation
In order to install the new assy, perform the removing operation in reverse
order.
5.4.4 Alpha Board Replacement
Required Tools
Socket wrench 5,5 mm
Removing (Figure 5.4)
1. By following the procedure of Para 5.4.1, remove the DISPLAY CORE
UNIT cover.
By following the procedure of Para 5.4.2, remove the ALPHA Expansion Board
and remove the hexagonal spacers, if that’s mounted.
Remove the terminal board’s connectors, the BNC and SMB connectors and
the flat cable from the board. Take note of their position.
By means of the 5,5 mm socket wrench, loosen and remove the nuts (pos. 1)
fixing the board (pos.2).
Remove the board.
Installation
In order to install the new board, perform the removing operations in reverse
order.
