Argus Radar - RADAR CONFIGURATION
988-10187-004 3.8
3.6 Unconventional sensor Cfg.
By pressing the “Unconventional sensor Cfg” button, the following window will appear:
Figure 3.6.1 Unconventional sensor Cfg.
With this function, it is possible to configure specific sensors (A) in addition to the
conventional sensors. For example, a GPS backup is useful when connected to ECDIS, a
wind sensor for conning wind information, an alarm monitoring system.
The menu above, as well as identifying the selected sensor, has the characteristic of
being able to set the serial port speed.
NOTE
This operation is possible only and exclusively if the various sensors are
directly connected to the RADAR.
