Argus Radar - RADAR CONFIGURATION
988-10187-004 3.11
3.7.2 Adjustment of the heading line
Pressing the C button of fig. 3.7.1. page 3.9, it is possible to set the Heading Line:
The Heading Line skew value can be set in two ways:
• Pressing the right or left arrow in order to turn the Radar picture clockwise or
counter clockwise with a precision of 1/10 of a degree, with the possibility to turn it
from -180° to +180°
• Placing the EBL on the angle where it is desired to place the HL and pressing the
"SET TO EBL" button, the picture will automatically turn, placing the angle where
the EBL was positioned on the Heading Line Marker.
Press the D button to select the correct Heading Line polarity, positive for a signal that is
zero with positive voltage as the active state, negative when the signal is bipolar (going
from negative to positive voltage) or active with a negative level.
Note: This function is only available when Alpha Extension board is installed.
WARNING
BUTTONS B AND D ARE AVAILABLE ONLY FOR THE RADAR VIDEO CHANNEL 1
AND 2.
CAUTION
IF THE CORRECT ANTENNA AND ANTENNA HEIGHT HAS NOT BEEN
SELECTED OR IF THE SEA TABLES WERE NOT CREATED, A DEFAULT
SETTING WILL BE USED. THE DEFAULT SETTING MAY, HOWEVER, NOT BE
THE OPTIMAL ONE FOR TARGET DETECTION IN THE SEA CLUTTER AND
TRACKING PERFORMANCE.
