Simrad argus - Additional Functions (Fig 3.11.1 - F)

Argus Radar - RADAR CONFIGURATION
988-10187-004 3.26
3.11.6 Additional Functions (Fig 3.11.1 – F)
Figure 3.11.6
In this configuration, it is possible to enable, disable or expand the ECDIS, Conning
Information and Twin Scan functions.
- ECDIS interface ( Figure 3.11.6-A)
Selecting/deselecting this function enables/disables transmitting the Overlay video to a
connected ECDIS. Clicking on the ”More” button expands the configuration window, and it
is possible to see the console for the radar that is enabled at that moment. For more
information, refer to the Technical User Manual.
Figure 3.11.6-A
- Simplified Conning Information Enable (Figure 3.11.6-B)
Selecting this function enables the Conning Tasks on the System Data Area Section (if the
wide screen configuration is being used).
A
B
C
