Argus Radar - INSTALLATION AND SETTINGS
988-10187-004 1.11
1.8 EPFS
The EPFS (Electronic Position Fixing System) signal is connected to TB3 on
the Alpha PCB.
When connected to an EPFS, the TB3 output sends relevant data for INS and
ECDIS.
NOTE
Supported EPFS equipment must follow the IMO
recommendation MSC.114(73)
1.9 AIS
The AIS signal is connected to TB8 on the Alpha PCB.
It's possible to receive RS422 or RS232 standard signal only at 38400 bps.
The sentences accepted are: AIALR, AIVDM and AIVDO.
NOTE
It is also possible to connect the output from the RADAR to the
AIS device, to acknowledge the alarms coming from AIS from
the RADAR interface. Normally, the AIS equipment has only
one input available, so that only one RADAR can be connected
to it and only one will be able to acknowledge the alarms. This
output is on the same serial port TB8 with only one sentence
generated: AIACK
The same output is the source for tracking data sentences TTD and TLB.
NOTE
Supported AIS equipment must follow the IMO
recommendation A.917(22)
1.10 BAM
Using same formatting as per EPFS:
The BAM (Bridge Alarm
Monitoring system) signal can be connected to TB10 or TB4 on the Alpha PCB.
NOTE
Supported BAM equipment must follow the IMO
recommendation MSC.252(83)
