5.7.3 Parts List Tables
List of the Units
Pos.
Fig.5.8
Description
Drawing
Specification
Number or Type
Required
Quantity
(N)
1
Simrad M5016
000-12209-001
1
1
Simrad M5019
000-12210-001
1
1
Simrad M5024
000-11781-001
1
1
Simrad M5027
000-12726-001
1
1
19” MMD SER 1ACRAL9011
000-10632-001
1
1
23” MMD SER 1ACRAL9011,
LED BACKLIGHT
000-10633-001 1
1
26” MMD SER 1ACRAL9011,
WIDE SCREEN
000-11570-001 1
2
Core unit for Argus 120/240 VAC
w/DOCS
000-10330-001 1
3
Multifunction Control Panel
000-11855-001
1
List of Items of DISPLAY CORE Unit
Pos. Description
Drawing
Specification
Number or Type
Required
Quantity
(N)
2
ANTARES ASSY
000-10688-001
1
3
ALPHA PCB ASSY
000-10691-001
1
4
ALPHA EXPANSION PCB ASSY
000-10690-001
1
6
POWER SUPPLY ELECTRONIC UNIT
000-10689-001
1
