1.12 Radar Console Failure Output
For installation where a continuous check of the radar console operability is
mandatory, a failure output is available.
The FAIL output is located on TB1 on the Alpha PCB and it is a NC contact that
can supply up to 200 mA of current (see Input/Output specification at this
Chapter’s introduction).
A special electronic circuit on the Antares PCB acts continuously as a watchdog
to detect any operational failure that can cause a processor malfunction.
Should a failure occur or the system is powered-off, the contact switches to
closed condition.
1.13 Configuration Links Table
1.13.1 Antares PCB Links:
Function
Ref.
Link Name
Description
Factory
Preset
BDM
J8
BDM
Enable B
Normally Open
Open
J11
BDM
Enable A
Normally Open
Open
Restore J7 SW
If closed at startup, the default
programs will not start and the
upgrade ÷ restore programs will be
run.
Open
1.13.2 Alpha PCB Links:
Function Ref. Link Name Description
Factory
Preset
Video
P7
VD1
Termination
Link closed when the Argus is
standalone or the last
equipment on the Video chain
Close
P12
VD2
Termination
Link closed when the Argus is
standalone or the last
equipment on the Video chain
Close
P2
422
Termination
Link closed when the Argus is
standalone on 422 serial
communication or the last
equipment on 422 serial
communication chain
Open
