Simrad argus - CHAPTER 8 Annex C

Argus Radar - ANNEX C
988-10187-004 8.1
CHAPTER 8 ANNEX C
System Installation Checklist
VESSEL:
Customer's ref:
Equipment type: DCORE (for all installed consoles) Serial n° :
A.
Gyrocompass Configuration
□
Gyro connected as:
Synchro
□
Stepper
□
NMEA
□
Fast NMEA
□
□
For Gyro Stepper connection
Reference generated internally
□
Negative Phases
□
□
For Gyro Synchro/Stepper connection
1:36
□
1:90
□
1:180
□
1:360
□
□
For Gyro NMEA/Fast NMEA connection
Com1
□
Com2
□
Com3
□
□
Check Gyro clockwise/anticlockwise rotation for synchro/stepper, after gyro preset
Check Gyro value validity with NMEA serial connection.
B.
Speed LOG Configuration
□
Speed LOG connected as:
100 p/NM
□ 200 p/NM □ 400 p/NM □ 120 p/mt
□
20000 p/NM
□
NMEA
□
□
For Speed NMEA connection
Dual Axis
□
Com1
□
Com2
□
Com3
□
□
Check Speed Log value validity with NMEA serial connection.
C.
Ownship Dimension and Weight
□
Width = ...... m
Length = ........ m
Weight = .............. T
D.
Conning and EPFS Position
□
Conning Position X = ...... m Y = ...... m
EPFS to Antenna Position X = ...... m Y = ...... m
