Argus Radar - INSTALLATION AND SETTINGS
988-10187-004 1.15
1.13.3 Alpha Expansion PCB Links:
Function Ref. Link Name Description
Factory
Preset
Video
P1
Video 1
Termination
Link closed when the Argus is
standalone or the last equipment on
the Video chain
Close
P2
Video 2
Termination
Link closed when the Argus is
standalone or the last equipment on
the Video chain
Close
P6
Video 3
Termination
Link closed when the Argus is
standalone or the last equipment on
the Video chain
Close
P8
Video 4
Termination
Link closed when the Argus is
standalone or the last equipment on
the Video chain
Close
P3
VD1 Level
Close in Serial Data Communication,
open in Combined Video and with
SRT Adapter Box installations
Close
P4
VD2 Level
Close in Serial Data Communication,
open in Combined Video and with
SRT Adapter Box installations
Close
Trigger
P5
Trigger 1
Termination
Link closed when the Argus is
standalone or the last equipment on
the Trigger chain
Close
P7
Trigger 2
Termination
Link closed when the Argus is
standalone or the last equipment on
the Trigger chain
Close
