Simrad argus - Page 161

Argus Radar - ANNEX C
988-10187-004 8.5
H.
TXRX Radar Console Settings
CS
□
NMEA
□
Trigger: Positive □ Negative □ Delay ...... m
QV Threshold: Auto
□ Manual □ ......
Video: Positive
□
Negative
□
I.
Video Level Adjustments
□
Video Amplitude of CH1 ......
Video Amplitude of CH2 ......
J.
System Configuration
□
Console 1 TXRX Default ...... Console 2 TXRX Default ......
Console 3 TXRX Default ...... Console 4 TXRX Default ......
K.
Final Checks
□
Check AIS target superimposition on correct radar echoes.
□
Check Interswitch function and Master/Slave operation.
□
Check CCRP correctness at the lowest scale displaying radar antenna position.
□
Backup Settings in USB Memory Module
Fields from A. to J. shall be fully compiled if the console settings
files are not made available to Simrad.
SYSTEM PERFORMANCE LIMITATIONS (BLIND SECTORS ETC..)
ADDITIONAL NOTES:
Setup and Installation was carried out according to Simrad Argus Radar System Installation & Service
manual and Scanner Manual(s).
Date ......./......./....... Report Compiled by:
