Argus Radar - SERIAL INTERFACE SPECIFICATIONS
988-10187-004 2.42
Antares PCB Serial In / Out Port Summary
Processor
Device and
Connector Name
Used For
Input
Type
Output
Type
Input /
Output Baud
Rate
A
ttyS0 Standard Out Console 232 232 57600
ttyS1 Keyboard 232 232 38400
ttyS2 TB10 Wind Sensor /RAALR 422/232 232 4800
ttyS3 TB4 BAM 422/232 232 4800
B
ttyS0 Standard Out Console 232 232 57600
ttyS1 TB9 Gyro 422/232 422 4800 / 38400
ttyS2 TB8
AIS In / AIS ACK and
TTD-TLB Out
422/232 422 38400
ttyS3 TB3 INS / EPFS / ECDIS 422/232 422 4800 / 38400
ttyS4 TB2 Speed Log 422/232 422 4800
ttyS5 TB6 Serial TXRX 1 422/232 422/232 4800
ttyS6 TB12 Serial TXRX 2 422/232 422/232 4800
