Argus Radar - RADAR CONFIGURATION
988-10187-004 3.2
3) Before entering the setup, a check dialog appear on screen with the following warning:
Fig 3.1.1 Security Check
The console setup is necessary for the commissioning of the system. From the console
display, using only the trackball, it's possible to configure and adjust all parts of the
system. Several functions of the console setup can normally only be accessed by an
authorized service engineer using a password to gain access. Please contat Navico
service if you need assistance.
Fig 3.1.2 Radar configuration Menu
A
B
C
D
E
F
G
H
I
M
N
L
O
