Argus Radar - RADAR CONFIGURATION
988-10187-004 3.20
To configure sector blanking, use up or down arrows to change the "Start Sector" and
the "End Sector" values. The graphic displayed on the PPI will change in real time, but
the command to the transceiver will be sent only after pressing the "Apply Sector" button.
Use "Discard" to discard temporary modifications to the sector blanking configuration.
The “on-off button next to the sector n label 1-2" shall be pressed to cancel the
current sector blanking.
NOTE
The settings of the Sector Blanking are stored directly in the TXRX and
not in the Argus Core Unit/display.
