Argus Radar - RADAR CONFIGURATION
988-10187-004 3.23
The table below shows which resolution is required for the different type monitors normally
connected to an Argus display:
Unit Type
Description
Aspect Ratio
Display Resolution
M5016 16” Simrad
16:9
1366x768
M5019
19” Simrad
16:9
1366x768
10CM-003
19" TFT Hatteland
5:4
1280x1024
10CM-004
19" TFT ISIC
5:4
1280x1024
10CM-005
23" TFT Hatteland
4:3
1600x1200
10CM-006 23" TFT ISIC
4:3
1600x1200
M5024
24” Simrad
16:9
1920x1080
10CM-008
26" TFT Hatteland
16:10
1920x1200
M5027
27” Simrad
16:9
1920x1080
To force the use of manual settings, click on the relative button “Force the use of Manual
Settings”, then confirm by clicking on “Yes” followed by “Accept”.
WARNING
Settings which are not automatically recognized are most probably not IMO approved
configurations. A warning: "NOT“APPROVED MODE” will appear in the System status
window.
