5 PICOSCALE HARDWARE
in one device also has the advantage that different data sources are synchronized and can be
handled with a single tool.
For easy access to the signals we recommend to use the PICOSCALE Breakout-Box which is de-
scribed in chapter 5.3. It includes additional buffering of analog and digital IOs and splits the
D-Sub 44HD connector to BNC connectors. However, for direct access via the D-Sub 44HD con-
nector, please contact SmarAct for information on the pin assignments.
