No.EX※※-OMX1011

•EX600-ED4/ED5-

No.

Description

Function

Power connector (PWR IN)

Supplies power for each unit and input/output devices.

Power connector (PWR OUT)

Provides power to downstream equipment.

Fixing hole for direct mounting

Holes used for direct mounting.

DIN rail fixing hole

Holes used for fix DIN rail.

F.E. terminal



Functional Earth terminal - must be connected directly to system earth

(ground).

: Individual grounding should be provided close to the product with a short cable.
