-45-
No.EX※※-OMS0027
•Digital input unit parameters
No. Parameter Definition Item Content
Default
setting
Parameter
setting range
Enable Generates an error.
○
1
The power
supply short
circuit
detection for
control and
input
Generates error
when the short
circuit of the power
supply for the input
device is detected.
Disable
Does not generate an
error.
Unit
Enable Generates an error.
2
Open circuit
detection

1
Generates error
when the
disconnection of
the input device is
detected.

2
Disable
Does not generate an
error.
○
Channel
Enable Ignores inrush current.
3
Inrush current
filter
Selects the over
current detection
for 100 msec after
supplying power.
Disable
Does not ignore inrush
current.
○
Unit
0.1 ms
1.0 ms
10 ms
4
Input filtering
time
Sets the time to
ignore the input
signal change.
20 ms
Selects the time for
filtering.
1.0 ms
Unit
1.0ms
15 ms
100 ms
5
Input
extension
time
Sets the time to
hold the input
signal.
200 ms
Selects the time to hold
the input signal.
15 ms
Unit
Enable
Generates an error.
Val: 1 to 65000

4
6
Input
ON/OFF
counter
Generates error
when the operation
count exceeds the
set value.

3
Disable
Does not generate an
error.
○
Channel
7
Input
ON/OFF
counter clear
Clears the Input
ON/OFF counter to
0. (Refer to page
83 for the clear
method).
-
- -
-
1: Disconnection detection is a function only available for digital unit (EX600-DXPC1, EX600-DXNC1) with disconnection detection.
2: 2-wire type input equipment cannot be correctly detected if its leakage current is 0.5 mA or less while the equipment is in the OFF state
(reed sensor, etc.).
Ensure that all input equipment used has a leakage current above 0.5 mA in the OFF state.
3-wire type input equipment cannot be correctly detected if its current consumption is 0.5 mA or less.
The open circuit of input signals cannot be detected.
3: The count is memorized every hour. When the power supply is turned on again, counting starts from the last value memorized.
4: Times for setting is set value x1000 times.
