•Analogue output unit parameters (2)
No.
Parameter
Definition
Item
Content
Default
setting
Parameter
setting range
7
Output setting
for
communication
idling
 
Sets output during
communication
idling.
Enable
Output will be user idle
value.
1
Channel
Disable
Output will be held last
state.

1: Set value shall be set per analogue input range within settable range in the table below.
When the analogue input range is changed, check the set value and change it to an appropriate value.
2: This function is valid only when "Hold/Clear priority" of the system parameter is set to "Via software".
3: Some PLC does not support an idle mode.
Settable range for user set upper or lower limit and output value at communication error and idling
Range
Settable range for user set upper or lower limit
Settable range for output
value at communication error
and idling
Lower limit
Upper limit
0..10 V
0.00 to +10.45 V
+0.05 to +10.50 V
0.00 to +10.50 V
0..5 V
0.00 to +5.22 V
+0.03 to +5.25 V
0.00 to +5.25 V
1..5 V
+0.75 to +5.22 V
+0.78 to +5.25 V
+0.75 to +5.25 V
0..20 mA
0.00 to +20.90 mA
+0.10 to +21.00 mA
0.00 to +21.00 mA
4..20 mA
+3.00 to +20.90 mA
+3.10 to +21.00 mA
+3.00 to +21.00 mA
Correspondence table for user set upper or lower limit and output value at communication error and
idling (E.O./W.S.)
(Data format: other than scale conversion format)
Range
Set value
(Offset Binary Signed Magnitude 2’s Complement)
Expected value
0..10 V
0 to 1050
0.00 to +10.50 V
0..5 V
0 to 525
0.00 to +5.25 V
1..5 V
75 to 525
+0.75 to +5.25 V
0..20 mA
0 to 2100
0.00 to +21.00 mA
4..20 mA
300 to 2100
+3.00 to +21.00 mA
: When the data format is a type other than scale conversion, input the desired voltage or current x 100 in decimal system.
: If the data format is scaled data format, set the data as follows, regardless of the range setting.
Correspondence table for user set upper or lower limit and output value at communication error and
idling (E.O./W.S.)
(Data format: scale conversion format)
E.O. set value
W.S. set value
Expected value
0 to 32767
0 to 32767
+0 to +32767
32768 to 65535
-0 to -32767
-0 to -32767
