171
System Settings Operations Paired Devices
Figure 14-4 Typical Device selection
A “in progress” message displays during the pairing procedure, which takes several seconds.
The Paired Devices screen displays once the procedure completes (Figure 14-5).
Figure 14-5 Typical Paired Devices screen
12. Select the Home icon on the toolbar to return to the Home screen.M2 Scope/Meter
13. After the M2 Scope/Meter has been successfully paired, turn the M2 Scope/Meter Rotary
Switch to the oscilloscope position.
14. Press and hold the F1 key to open the alternate menu.
15. Press the F4 key (once) to turn off (disable) Bluetooth Discovery mode.
The F4 field on the screen switches to normal video (black on white) when the Bluetooth
Discovery mode is inactive (Figure 14-6).
Once the M2 Scope/Meter is initially paired with the diagnostic tool, additional pairing is not
necessary. Although the discovery mode has been disabled, the two-paired devices
automatically seek and find each other when they are both powered on. The M2 Scope/Meter
becomes “invisible” to other Bluetooth devices whenever Bluetooth Discovery is disabled.
4$"/.0%6-&
4$01&.&5&3.
4$"/.0%6-&
