11
D335 User Manual Setting up the Phone
2.
marked (Fig. 1 and 2).
Attaching for wall mounting
See "Appendix 3 - Wall Mounting" on page 115.
Detaching
backwards and lift it from its anchorage in the mounting holes (Fig. 2).
Fig. 1 Fig. 2
Rotating the tab of the cradle
The phone is delivered with the tab level with the inner edge of the cradle (Fig. 1). If you are going
to mount the phone on a wall, we recommend that you rotate the tab 180°. After rotation, the tip of
the tab (Fig. 4) will protrude slightly above the edge of the cradle. The small rectangular hole in the
upright position on the wall.
Fig. 1 Fig. 2 Fig. 3 Fig. 4
1. Slide the plastic tab from the cradle (Fig. 2)
2. Rotate the tab 180°.
3. Slide the tab back into the cradle (Fig. 3).
