D335 User Manual Appendix 3
Appendix 3 - Wall Mounting
The four screws and two screw anchors/molly bolts/wall plugs appropriate for your type of wall are
not included in the delivery.
Distance to wall
Abstand zur Wand
Distance au mur
Distanza dalla parete
Distancia a la pared
Distância à parede
∼ 5 mm (0.197")
ø max
8 mm
(0.315")
ø max
4,5 mm
(0.177")
70,00 mm (2.756")
133,00 mm (5.236")
133,00 mm (5.236")
1. Before attaching the footstand in the position for wall mounting, plug the long end of the handset
cord into the connector labelled " " on the bottom of the phone and place the cord in the cable
guide (Fig. 1).
Fig. 1
2.  (Fig. 2).
3. 
marked 
mounting the phone on the wall.
Not included in delivery:
4x
