Inverter Interfaces
Thefollowingfigureshowstheinverterconnectorsandcomponents,locatedatthebottomofthe
inverter.
Figure 7: Inverter Interfaces
l AC and DC conduit entries:ConnectionpointsoftheConnectionUnit.
l Two communication glands,forconnectionofinvertercommunicationoptions.Eachglandhas
threeopenings.RefertoSettingUpCommunicationtotheMonitoringPlatformonpage72formore
information.
l LCD light button:PressingthisbuttonlightsuptheLCDfor30seconds.Inaddition,youcanpress
thisbuttontoviewinverterstatusscreensandaccessconfigurationmenuoptions,asdescribed
ConfiguringtheInverterUsingtheLCDLightButtononpage57.
l ON/OFF switch:TurningthisswitchON(afterthepoweroptimizersarepairedwiththeinverter)
startstheoperationofthepoweroptimizers,enablespowerproductionandallowstheinverterto
beginexportingpowertotheutilitygrid/backed-uploads.TurningitOFFreducesthepower
optimizervoltagetoalowsafetyvoltageandinhibitsexportationofpower.WhenthisswitchisOFF,
theinvertercontrolcircuitryremainspoweredup.
l LCD panel:displaysinverterinformationandconfigurationparameters
l LCD LEDs:ThreeLEDsindicatethefollowinginverterstatuses:
Color Description Functionality
Green Power production
On - The inverter is producing power.
Blinking - Standby mode. The inverter is in Standby mode until its
working voltage is reached. The inverter then enters Production
mode and produces power.
Off - The inverter is not producing power. This may be during Night
mode, when the inverter ON/OFF switch is OFF or when an error
occurs.
Yellow
Module communication and
inverter shutdown
Blinking:
o
Monitoring information is being received from a power
optimizer.
o
The inverter is being shut down.
Red Fault
On - There is an error. Refer to Troubleshooting on page 93 for
more information.
Blinking - The inverter is being shut down.
AllLEDsturnonwhiletheinverterisbeingconfigured.
Chapter 3: Installing the Inverter
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.3
21
