StorEdge Single Phase Inverter with
Connection Unit for High Power - Technical
Specifications
StorEdge Inverter
SE7600A-US
1
Unit
Lower Power Output Higher Power Output
OUTPUT - AC (LOADS/GRID)
Rated AC Power Output 7600 VA
Max AC Power Output 8350 VA
AC Output Voltage Min-Nom-Max (L-L)
2
211-240-264 Vac
AC Frequency Min-Nom-Max (1) 59.3 - 60 - 60.5 Hz
Maximum Continuous Output Current
@240V
32 A
GFDI 1 A
Utility Monitoring, Islanding Protection,
Country Configurable Thresholds
Yes
Charge Battery from AC (if Allowed) Yes
THD < 3 %
Power factor with rated power >0.99 (configurable; 0.9 leading to 0.9 lagging)
Typical Nighttime Power Consumption <5 W
OUTPUT - AC (BACKUP POWER)
3
Rated AC Power Output 5000
4
VA
Max AC Power Output - Surge 6600
4
VA
AC Output Voltage Min-Nom-Max (L-L) 211-240-264 Vac
AC Output Voltage Min-Nom-Max (L-N) 105-120-132 Vac
AC Frequency Min-Nom-Max 55 - 60 - 65 Hz
Maximum Continuous Output Current
@240V - Backup Mode
21 A
Max Continuous Output Current per
Phase @120V
25 A
GFDI 1 A
1
These specifications apply to inverters with part numbers SE7600A-USS2XXXXX and connection unit model number
BCU-1PH-USS.
2
For other regional settings, contact SolarEdge Support.
3
Not designed for standalone applications and requires AC for commissioning.
4
The rated AC power output is the minimum between the AC Power Output and the battery continuous peak power.
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.3
110
StorEdge Single Phase Inverter with Connection Unit for High Power - Technical
