SolarEdge SEAUTO-TX-5000 - Setting Backup-Only Mode; Configuring Backup-Only Mode

Setting Backup-Only
WhentheinverterissettoBackup-onlymode,thebatterywilldischargetosupplypowertothebacked-
uploadsonlyuponpoweroutage.
To set up Backup-only:
1. AccesstheEnergy Ctrlmenuasdescribedabove.
2.
SelectBackup only.TheEnergyManagerscreenchangestodisplaythefollowing:
L i m i t C o n t r o l < D i s >
E n e r g y C t r l < B U >
S t o r a g e C o n t r o l
Setting MSC + Backup Power
Inthismode,youfirstsetthesystemtomaximizeself-consumption(MSC),andthenthelevelofstored
energytobereservedforbackup.
To set up MSC + Backup Power:
1. AccesstheEnergy Ctrl.menuasdescribedabove.
2.
Formaximizingselfconsumption,selectMax Self-Consume.TheEnergyManagerscreenchangesto
displaythefollowing:
L i m i t C o n t r o l < D i s >
E n e r g y C t r l < M S C >
S e t O p e r a t i o n
S t o r a g e C t r l
3.
Optionally,setthebatteryOFFperiodsasfollows:
a.
SelectSet Operation.Alistisdisplayed,allowing12monthlyprofilesetup:
J a n < O N >
F e b < O N >
M a r < O N >
A p r < O N >
b.
Selectamonth.Alistofoptionsisdisplayed.
S t a r t T i m e < 0 0 : 0 0 >
E n d T i m e < 0 0 : 0 0 >
A l w a y s O N
A l w a y s O F F
c.
Selectoneoftheoptions:
l SelectAlways OFFtoavoidbatteryusageentirely(forexampleduringwinter)
l SetStart TimeandEnd Timetosetbatteryusageinspecifichoursandavoidusageduring
specifichoursthroughoutthemonth(forexampleatnight).Thissetstheperiodsduring
whichthebatterywillbeintheOFFstate.
l SelectAlways ONtousebatteryatalltimesforcharging/discharging.
4.
Tosetaminimumbatterylevelusedforbackup,sothatthebatterywillalwayshaveenergystoredin
casebackuppowerisneeded,dothefollowing:
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.3
88
