SolarEdge SEAUTO-TX-5000 User Manual

Connecting to the Battery
Tosimplifytheconnectionprocessitisadvisedtoconnectthebatterytotheinverterbeforemounting
thebatteryaccordingtothemanufacturerinstructions.
Followtheseguidelines:
l Foreasyaccesstobatteryconnectors,itisrecommendedtoconnectthecablestothebatteryand
tosetallthebatteryDIPswitchestotheircorrectpositionswhilethebatteryisstillontheground,
beforemountingthebatteryaccordingtothemanufacturerinstructions).Thefollowingprocedureis
recommended:
a. Connectallthewirestothebatteryconnectionpanel
b. Mountthebattery
c. Assembletheconduitbetweenthebatteryandtheinverter
d. ConnecttotheConnectionUnit.
l MeasurethenecessarylengthbetweentheConnectionUnitandthebatteryforallcables.The
maximumdistancebetweenthebatteryandtheinverteris35ft/10m,whenusing24AWG/0.2mm
2

cablesforbatterycontrol.
l Tieandwrapthecablestoavoidpullingthemoutduringmounting.
l Besuretoadheretoallsafetycautionsandinformationinthebatterydocumentation.
l ThebatteryconnectstotheDCsideoftheinverter.SincetheinverterDCconnectionsareonitsleft
side,itisrecommendedtopositionthebatterytotheleftoftheinvertertosimplifywiring.
WARNING!
The battery should be powered OFF before and during wiring. Turn OFF:
l The auxiliary power supply switch
l The circuit breaker switch

Labatteriedoitêtreétteinteavantetpendantlecâblage.Fermer:
l Lecommutateurd'alimentationauxiliaire
l Lecommutateurducoupeur

SolarEdge-StorEdge Installation Guide MAN-01-00262-1.3
34
Connecting to the Battery
