Thecellularkitcanbepurchasedseparatelyandassembledduringsysteminstallation.
Thekitisprovidedwithausermanual,whichshouldbereviewedpriortoconnection.
Refertohttps://www.solaredge.com/sites/default/files/cellular_cdma_kit_installation_
guide_na.pdf.
Communication Connectors
Twocommunicationglandsareusedforconnectionofthevariouscommunicationoptions.Eachgland
hasthreeopenings.Thetablebelowdescribesthefunctionalityofeachopening.Unusedopeningsshould
remainsealed.
Gland# Opening Functionality Cable Size (diameter)
1 (PG16)
One small External antenna cable 2-4 mm
Two large
Ethernet connection (CAT5/6),
ZigBee, Cellular
4.5-7 mm
2 (PG13.5) All three RS485, power reduction 2.5-5 mm
Figure 32: Communication Glands
ThecommunicationboardhasastandardRJ45terminalblockforEthernetconnection,anda9-pin
terminalblockforRS485connection,asshownbelow:
Figure 33: Internal connectors
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.3
74
