l Status:DisplaysOKifthemeteriscommunicatingwiththecommunicationboard.
l <Error message>:Ifthereisametererror,itisdisplayedinthisline.RefertoMeterTroubleshootingon
page94.
l Power (W):Dependingonthemetertypeconnectedtotheinverter,thislinedisplaystheexported
orimportedpowerinWatts.
l Energy (Wh):Thetotalenergyreadbythemeter,inWatt/hour.Thevaluedisplayedinthisline
dependsonthemetertypeconnectedtotheinverteranditslocation:
o
Ifabidirectionalmeterisconnectedattheconsumptionpoint,thisvalueistheconsumedenergy.
o
Ifthemeterisinstalledattheproductionconnectionpoint,thisvalueistheenergyproducedby
thesite.
o
Ifthemeterisinstalledatthegridconnectionpoint,thisvalueistheenergyexportedtothegrid.
IftheinverterisconnectedtotheSolarEdgeserver,thisvaluewillalsobedisplayedinthemonitoring
platform.
NOTE
This data is accumulated according to an internal real-time clock.
Telemetry Status
Thisscreendisplaysthelastpoweroptimizertelemetryreceived.Thedisplaychangesaseachpower
optimizersendsitstelemetry.
Inordertoverifyproperinstallation,theinstallermayviewtheTelemetrywindowforsometimeinorder
toobservethepoweroptimizers'reportprocess.
M o d u l e : 1 0 2 8 8 0 6 3 1 B
E n e r g y [ W h ] : 5 6 . 7
V d c _ O [ V ] : 4 0 . 0
V d c _ I [ V ] : 3 8 . 3
I _ i n [ A ] : 7 . 8
T e m p [ C ] : 2 8 . 0
l Module:Poweroptimizerserialnumber
l Energy:poweroptimizerenergy
l Vdc_O:Poweroptimizeroutputvoltage
l Vdc_I:Poweroptimizerinputvoltage(modulevoltage)
l I_in:Poweroptimizerinputcurrent
l Temp:Poweroptimizertemperature
ID Status
Thisscreendisplaystheinvertersoftwareversionandthecountrytowhichtheinverterisconfigured.
I D : # # # # # # # # # #
D S P 1 / 2 : 1 . 0 2 1 0 / 1 . 0 0 3 4
C P U : 0 0 0 3 . 1 9 x x
C o u n t r y : U S A 1
l ID:TheinverterID.
l DSP 1/2:TheDSPdigitalcontrolboardfirmwareversion
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.3
66
