Chapter 8: User Interface
LCD User Buttons
FourbuttonsarelocatedinsidetheinverterabovetheLCDpanelandareusedforcontrollingtheLCD
menus,asshownbelow:
Figure 31: LCD Internal menu buttons
UsethefouruserbuttonstocontroltheLCDpanelmenus:
l Esc:Movesthecursor(>)tothebeginningofthecurrentlydisplayedparameter;goestotheprevious
menu,andcancelsavaluechangewithalongpress(untilAborted isdisplayed).
l Up (1)andDown (2):Movesthecursorfromonemenuoptiontoanother,movesamongthe
charactersofadisplayedparameter,andtogglesbetweenpossiblecharacterswhensettingavalue.
l :Selectsamenuoptionandacceptsavaluechangewithalongpress(untilAppliedisdisplayed).
TheLCDscreendisplaysstatusinformationofthesystemandvariousmenusforconfigurationoptions.
TheLCDpanelandbuttonsareusedduringthefollowingprocesses:
l Operational mode:TheLCDpanelallowscheckingforpropersystemoperation.RefertoStatus
Screens-OperationalModeonpage65foradescriptionofthisoption.
l Setup mode:Uponinstallation,aninstallermayperformbasicconfiguration.
l Error messages:Intheeventofaproblem,anerrormessagemaybedisplayedontheLCDpanel.
Formoreinformation,referto
https://www.solaredge.com/sites/default/files/troubleshooting_for_se_inverter_
insallation_guide_addendum_na.pdfandInverterConfiguration–SetupModeon
page54.
Chapter 8: User Interface
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.3
53
