DIPSwitch Setup
VerifythattheDIPswitchesonthesystemcomponentsaresetasdescribedinthissection,accordingto
thesystemhardwareconfiguration.
DIPSwitch Setup in Meter and Inverter
Terminationandbiasguidelines:
l ThelastexternalmeterintheRS485chainshouldbeterminatedwith120Ohm(eitherinternalor
external).
l Invertercommunicationboard(Figure23):
o
Ifameterisinstalled:Notermination-LeftSW7switchDown
o
Ifameterisnotinstalled:terminationON-LeftSW7switchUp(seealsoCreatinganRS485Bus
Connectiononpage77)
Figure 23: RS485 termination switch on the inverter communication board
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.3
38
DIPSwitch Setup
