Recommended
cable type (min-
max AWG)
Connection Unit
connection
Auto-transformer
connection
Connection method
Temperature Sensor
Temperature sensor
terminal
24 AWG (16-24 AWG),
300 Vrms insulated
External Devices 7-pin
terminal block: T1
Temperature sensor
terminal: T1
1
Connection Unit: Press the
protrusion at the top of the
terminal block to open the
connection hole, insert the wire
and release to spring back and
clamp the wire.
Auto-transformer:
o
Insert a flat blade screwdriver
into the square opening at the
top of the terminal block and
press to open clamp
mechanism.
o
Insert the wire into the round
opening and release the
screwdriver to spring back and
clamp the wire.
External Devices 7-pin
terminal block: T2
Temperature sensor
terminal: T2
1
T1 and T2 are interchangable
SolarEdge-StorEdge Installation Guide MAN-01-00262-1.3
42
Connecting to the Auto-transformer
