SolarMax SM30HT4 - Page 48

48
Function / parameter Description Unit / status
QMCCP-VLE Status of mains voltage-dependent reactive power
control hysteresis for QMCCP
Disabled/enabled
QMCCP-VLIH Mains voltage switch on value V
QMCCP-VLOL Mains voltage switch off value V
QMCCP-PLE Status of active power-dependent reactive power
control hysteresis for QMCCP
-
QMCCP-PLI Active power switch on value W
QMCCP-PLO Active power switch off value W
Grid stabilization
Functions and parameters of the "Grid stabilization" sub-menu:
Function / parameter Description Unit
FRT Fault Ride-Through function -
FRT-ENA FRT function status Disabled/enabled
FRT-TRV Mains voltage trip value V
FRT-RCM Reactive power mode -
FRT-KF K factor -
FRT-TM1 Timer 1 s
FRT-TM2 Timer 2 s
Reference parameters
Functions and parameters of the "Reference parameters" sub-menu:
Function / parameter Description Unit
NAP Rated output power (Pac nom) -
NAP-VAL Value W
NOC Rated output current -
NOC-VAL Value A
GCD Coupler breaker switch delay -
GCD-CDLY Trip time s
