Function / parameter Description Unit / status
QMCQ-QSV Reactive power value % of Pac nom
[OEX/UEX]
QMCQ-VLE Status of the voltage-dependent reactive power
control hysteresis for QMCQ
Disabled/enabled
QMCQ-VLI Mains voltage switch on value V
QMCQ-VLO Mains voltage switch off value V
QMCQ-PLE Status of the active power-dependent reactive
power control hysteresis for QMCQ
Disabled/enabled
QMCQ-PLI Active power switch on value W
QMCQ-PLO Active power switch off value W
QMCPP
Reactive power mode "cosφ(Pac)"
-
QMCPP-PSP1 to
PSP10
Characteristic values 1 to 10 of Pac active power % of Pac nom
QMCPP-CPSP1 to
CPSP10
Characteristic values 1 to 10 of power factor cosφ
- [UEX/OEX]
QMCPP-VLE Status of mains voltage-dependent reactive power
control hysteresis for QMCPP
Disabled/enabled
QMCPP-VLI Mains voltage switch on value V
QMCPP-VLO Mains voltage switch off value V
QMQU1 Reactive power mode "Q(Vac) mode 1" -
QMQU1-VSP1 to VSP10 Characteristic values 1 to 10 of mains voltage (Vac) V
QMQU1-CPSP1 to
CPSP10
Characteristic values 1 to 10 of reactive power Q % of Pac nom
[UEX/OEX]
QMQU1_DLY Delay time when mains voltage (Vac) changes s
QMQU1-VLE Status of active power-dependent reactive power
control hysteresis for QMQU1
Disabled/enabled
QMQU1-VLI Active power switch on value % of Pac nom
QMQU1-VLO Active power switch off value % of Pac nom
QMQU2 Reactive power mode "Q(Vac) mode 2" -
QMQU2-UPQ Upper reactive power value (OEX) % of Pac nom
QMQU2-LOQ Lower reactive power value (UEX) % of Pac nom
QMQU2-UPVLI Mains voltage switch on value for QMQU2-UPQ V
QMQU2-UPVLO Mains voltage switch off value for QMQU2-UPQ V
QMQU2-LOVLI Mains voltage switch on value for QMQU2-LOQ V
QMQU2-LOVLO Mains voltage switch off value for QMQU2-LOQ V
QMQU2-PLE Status of active power-dependent reactive power
control hysteresis for QMQU2
Disabled/enabled
QMQU2-PLI Active power switch on value % of Pac nom
QMQU2-PLO Active power switch off value % of Pac nom
QMCCP
Reactive power mode "cosφ"
-
QMCCP-CPSV
cosφ value
- [UEX/OEX]
