DAW Control
SE
LECT
MO
DE
All 24 channel SEL buttons become track select buttons. They perform the same function as clicking with the mouse on
a
channel in the DAW.
A double click on a
SEL button will open the channel naming pop-up for that channel.
Multiple channels can be selected by holding down the
SHIFT button while selecting further SEL buttons or by holding
down the first SEL button you pressed while you select more channels. Note that this last method only works within
b
locks of channels corresponding to a single HUI interface.
Hold down
OPTION and press any SEL button to select all channels.
Hold down
ALT and press any SEL button to invert the state of all select buttons.
WORKING WITH THE CHANNEL V-POTS
The channel V-pots can control DAW channel pan, Send (Aux) levels and pan, routing assignment and analogue audio
levels. Each V-pot also has a switch which is activated by pushing down on the V-pot.
The channel V-pot function is selected on the Master Control Panel by the Master Send V-pot ( ) and six associated
buttons ( ).
The scribble strip above the channel V-pots shows which function is currently selected. A further two buttons
(PRE/POST and MUTE, ) change the function of the V-pot push switches.
PAN MODE
Select PAN mode and the channel V-pots become pan controls for the DAW. The V-pot scribble strip displays ‘Pan’.
Pressing the PAN button on the Master Control Panel a second time (it flashes in this mode) allows you to access a
second pan control for stereo channels according to your DAW configuration. The V-pot scribble strip displays ‘Pan R’ in
this mode.
Press the PAN button again to return to normal pan mode.
When panned centrally a red LED appears just beneath the channel V-pot.
Holding down ALT displays a pan’s numeric value on the channel scribble strip when you adjust the control.
CHANNEL MODE
Select CHANNEL mode and the channel V-pots control the analogue gain of the channel strip. The V-pot scribble strip
will display the analogue fader number (eg ‘Fader 12’).
Switching to Analogue Focus mode will swap the analogue gain and the DAW gain between V-pot and channel fader.
Individual channels can be swapped by pressing the channel V-pot.
SEND MODE
Select SEND mode on the Master Control Panel and the V-pots become level controls for any sends or aux send levels
within the DAW.
The Master Send V-pot ( ) selects which of the available sends (A-E or 1-5) is being controlled by the channel V-pots.
The selected send is shown in the display window above the Master Send V-pot (and on the channel V-pot scribble strip).
The channel V-pot scribble strips show the name of the currently selected send. Turning a channel V-pot will alter the
level of the selected send from that channel. Holding down the
ALT button allows you to make fine adjustments to the
gain.
2
31
4
2
5
1
1
1
Page 4-12 AWS δelta Owner’s Manual
