CONSOLE SETUP MENU
The centre section TFT screen provides access to a setup menu that holds a number of useful console-related items. Select
SSL followed by Misc and then Setup.
Note that a VGA connector on the back of the console allows the console’s screen to be displayed on an external
monitor. See Section 1 for details.
To change a setting, use the left hand V-pot ( ) to select the item, then press the V-pot to enter adjustment mode.
Turn the V-pot to the desired setting and press again to save the setting.
The Setup options are described over the following pages.
1
Analogue Operations
Page 3-30 AWS δelta Owner’s Manual
TR Auto LnksMisc DAW SSL
Setup
R
estart
I
n Mix show : Channel names in Mix running
P
roject Testing :: Title
Latched Match and Play : OFF
Talkback switces are : Auto (Play)
Listen switch is : Auto (Play)
Red light switch is : Auto (Record)
MIDI connects via : Network
DAW 1 : Protocol HUI
Monitor Gain display : Gain (Off to 0dB)
Monitor set CAL level is : 85
DAW 2 : Protocol Nuendo
1
‘MISC/SETUP’ KEYS
‘SSL’ KEY
‘RESTART’ KEY
To Next Page
